| WIRE CUT EDM |
———————————————————————————————————————————— |
|
| |
| TECHNICAL SPECIFICATIONS |
|
Brass Material Specs. |
: |
Equivalent to JIS H3260 C2700W Standards |
|
|
Material Composition |
: |
Cu / Zn : 65% / 35% |
|
|
Wire Diameters |
: |
0.20mm, 0.25mm |
|
|
Diameter Tolerance |
: |
-0.000 mm, -0.002 mm |
|
|
Tensile Strength |
: |
Hard Wire |
|
: |
950 -1000 N/mm 2 (96-102 kgf/mm2 ) |
|
|
|
SemiHard Wire |
: |
480-520 N/mm 2 (49-53 kgf/mm2 ) |
|
|
|
Soft Wire |
: |
300-380 N/mm 2 (31-39 kgf/mm2 ) |
|
|
|
|
|
|
|
|
|
| |
| PRODUCT RANGE & SPECIFICATIONS |
———————————————————————————————————————————— |
Diameter
|
Product Code
|
Tensile St
(N/mm 2 ) |
Grade |
Spool
(JIS/DIN) |
Net Wt
(kg) |
Length
|
Ctn Pack
|
Wt/Ctn
|
0.20 mm
|
SE-H20P3R |
950-1000 |
Hard |
P3R |
3.0 kg |
11.5 km |
6 spls/ctn |
18.0 kg |
SE-H20P5R |
950-1000 |
Hard |
P3R |
5.0 kg |
19.1 km |
4 spls/ctn |
20.0 kg |
0.25 mm
|
SE-H25P3R |
950-1000 |
Hard |
P3R |
3.0 kg |
7.3 km |
6 spls/ctn |
18.0 kg |
SE-H25P5R |
950-1000 |
Hard |
5.0 kg P3R |
5.0 kg |
12.2 km |
4 spls/ctn |
20.0 kg |
|
| |
| PLASTIC REEL DIMENSIONS |
———————————————————————————————————————————— |
SPOOL |
SPOOL SIZE (mm) |
TYPE |
D1 |
D2 |
W1 |
W2 |
d |
P-3R |
130 mm |
80 mm |
110 mm |
90 mm |
20 mm |
P-5R |
160 mm |
90 mm |
114 mm |
90 mm |
20 mm |
|
|
| |
|
